The Sweet Spot for Azure Kubernetes Service Multi-Tenancy

Introduction

Created with DALL-E 3

Azure Kubernetes Service (AKS) is a powerful tool for managing containerized applications at scale. However, as organizations adopt AKS, the question of multi-tenancy often arises: how do you design an architecture that balances reliability, cost, and security when serving multiple tenants? For smaller companies with limited funding, where cost-optimization is paramount, this question is particularly crucial.

Having worked at a large Fortune 50 organization, where cloud cost was not always a critical strategic decider, I witnessed firsthand how cloud costs, initially seen as manageable, ballooned over time and became a significant issue. Cloud costs became such a significant issue, that they contributed to cost-cutting across IT, including layoffs (or RIFs as they are colloquially known). Now, working for a smaller organization, I’ve come to appreciate the “magic triangle” of cloud cost (directly related to funding), reliability and security. These three elements must work hand in hand to build a sustainable, scalable, secure and cost-conscious infrastructure. What does this mean in the context of Azure and Kubernetes?

The answer lies in identifying the “sweet spot” for multi-tenancy. While the Azure Architecture Center outlines several approaches with pros and cons, there is a sweet spot for startups and smaller organizations. This post explores that sweet spot: using namespaces as tenant separators to separate transactional workloads, combined with strict security measures to maintain isolation and control.

Why Namespace-Based Multi-Tenancy?

Namespaces in Kubernetes provide logical separation within a cluster, making them an ideal candidate for multi-tenancy in cost-conscious environments. Here are a few reasons why namespace-based separation is appealing:

1. Cost Efficiency: Running separate clusters for each tenant can be prohibitively expensive. By sharing a single AKS cluster, you reduce the operational and financial overhead associated with maintaining multiple clusters.

2. Resource Management: Kubernetes namespaces allow you to apply resource quotas, limits, and policies at the namespace level. This enables you to allocate resources fairly and prevent tenants from over-consuming cluster resources.

3. Scalability: A namespace-based approach is well-suited to scaling tenant workloads within a single cluster, allowing smaller companies to start lean and expand gradually.

Achieving Secure Namespace Separation

Security is a common concern when sharing a cluster across multiple tenants. To address this, it is critical to implement robust measures that prevent cross-tenant interference.

Kubernetes’ built-in network policies can enforce strict traffic isolation. For example, you can configure network policies to:

• Block communication between namespaces.
• Allow traffic only from trusted ingress controllers.
• Restrict egress traffic to specific external endpoints.

To limit network traffic for pods within a namespace so that they can only communicate with other pods in the same namespace, you can define a Kubernetes NetworkPolicy as follows:

   apiVersion: networking.k8s.io/v1
   kind: NetworkPolicy
   metadata:
     name: <restrict-to-namespace>
     namespace: <your-namespace-name>
   spec:
     podSelector: {}
     policyTypes:
     - Ingress
     - Egress
     ingress:
     - from:
       - podSelector: {}
     egress:
     - to:
       - podSelector: {}

There you have it! Pretty simple and straightforward. We can use NetworkPolicy to balance security and optimize cost using a single Kubernetes cluster. For more information and more complex scenarios, take a look at the official Kubernetes Network Policies documentation.

Separate Resource Groups

However, here I must caution you against using namespaces for anything but purely transactional workloads that do not store data. While technically possible, I find it more challenging. While namespaces handle separation within a cluster for transaction based processing through pods, other Azure resources that store data (such as Storage Accounts, Databases, Key Vaults, etc.) should reside in tenant-specific Resource Groups (RGs). Data needs to be strictly separated to maintain compliance and security. Azure Platform as a Service (PaaS) offerings separated in tenant-specific RGs offload operational burden for organizations with limited staff and funding.

Final Thoughts

For startups and smaller companies, namespace-based multi-tenancy offers a pragmatic balance between cost and control. By leveraging namespaces for separation and implementing strict security measures, you can create a multi-tenant architecture that scales with your business.
